| | Standby | ≤3W |
| | Working | <135W |
| | Black, white, green, pink, ivory, wine, blue, violet... | |
| Body material | Durable aluminum frame + tempered glass to protect LCD panel against external impacts | |
| | CPU | T982 |
| | RAM | 4GB |
| | Memory | 32GB |
| | GPU | Mali-G52 MP2(2EE) |
| | Operation System | Android 13 |
| | WIFI network | IEEE802.11an 2.4GHz |
| | Mirroring hotspots | Dual bands (IEEE802.11 a/b/g/n Dual Band 2.4GHz/5 GHz) |
| | Bluetooth | BT:v2.1+EDR/BT V3.0/BT V3.0+HS/BT V4.0 |
| | Remote Distance | 12 meters |
| OPS | CPU | I3/I5/I7 |
| HDD | SSD 128GB |
| WIFI | IEEE802. 11an 2.4GHz |
| Graphics | Intel ®HD Graphics |
| Touch Screen (Multi-Points) | Detection Method | Infrared touch,Multi-points, 20 touch points |
| | Position accuracy | Approximately 3 mm absolute, 1 mm relative. No drift |
| | Alignment | Software drivers provide a calibration facility |
| | Sensitivity | Can be programmed for different thickness of glass and even use with gloved hands |
| | | Standard configuration functions with non-metalized |
| | | Single construction glass 16mm thick. Double glazing option up to 25mm available |
| | Speed of response | Depends upon material thickness. Typically 50 to 100ms |
| | Output | USB 2.0 |
| | Software Compatibility | Drivers are available for Windows Operating Systems |
| | Temperature range | Better than -10 to +70°C |
| | Humidity Controller | 0% to 95%. Unaffected by condensation |
| Metal Case | Material | Aluminum frame + metal casing + toughened glass |
| | Surface | Metal case with powder burning; tempered glass to protect LCD panel |
| | Speaker | 2*12W built-in stereo speakers |
| | Heat Dispersion | Built-in DC heat sink |
| | Interface | In the rear: USB for touch, RJ45 Lan port, AV in, AV out, Earphone port, SPDIF out, HDMI input port, DB9 RS232, USB2.0, USB3.0, OPS interface port In the front panel: 2x USB2.0, USB3.0, HDMI input, USB for touch |
| | Reset Button | External reset button for ease of operation |
| | Extension | Mini Printer or A4 laser printer, Camera, Coin acceptor, Biology fingerprint recognizer, IC/ID card reader, Standard US Keyboard or metal explode proof, keyboard, 16bit Metal Keyboard, Infrared receiver, 2/3 track Magnetic Card reader, Explode proof metal |
